Details
| 1. X/Y/Z axes travel (Vertical) | : | 500/500/450 mm |
| 2. X/Y/Z axes travel (Horizontal) | : | 500/450/500 mm |
| 3. Vertical spindle nose to table top | : | 125-575 mm |
| 4. Horizontal spindle nose to table center | : | 125-625 mm |
| 5. Horizontal spindle center to table top | : | 75-525 mm |
| 6. Table load capacity | : | 350 kg |
| 7. Spindle speed | : | 10000~12000 rpm |
| 8. Spindle motor | : | 7.5/11.0 kW |
| 9. Rotary table dimension | : | 400x400 mm |
